V10E385P

LITTELFUSE  V10E385P  金属氧化物MOV压敏电阻

620V 3.5kA Varistor 1 Circuit Through Hole Disc 10mm

立创商城:
V10E385P

得捷:
VARISTOR 620V 3.5KA DISC 10MM

贸泽:
压敏电阻 385V 10mm Epoxy UltraMOV

e络盟:
LITTELFUSE  V10E385P  金属氧化物MOV压敏电阻

艾睿:
Apply different voltages to this V10E385P MOV from Littelfuse in order to change resistance of it. Its maximum surge current is 3500 A. This part has a pitch of 7.5 mm. This device&s;s clamping current is 25 A and clamping voltage is 1025 V. This voltage dependent resistor has an operating temperature of -55 to 85 °C. This product comes packaged in bulk, so the parts will be stored loosely. The maximum AC voltage rating is 385 VAC and the maximum DC voltage rating is 505 VDC. This product is 17 mm tall and 7.3 mm deep with a diameter of 12.5 mm. This device is made with metal oxide technology. This varistor has a voltage of 682 V. Its capacitance value is 160pF.

Chip1Stop:
Var MOV 385VAC/505VDC 3500A 682V Radial Bulk

Newark:
# LITTELFUSE  V10E385P  TVS Varistor, MOV, 385 V, 505 V, UltraMOV Series, 1.025 kV, Disc 10mm, Metal Oxide Varistor MOV
