LITTELFUSE V230LA40AP 金属氧化物MOV压敏电阻
Description
The LA Series of transient voltage surge suppressors are radial leaded varistors MOVs that are designed to be operated continuously across AC power lines. These UL recognized varistors require very little mounting space, and are offered in various standard lead form options.
Features
• Lead–free, Halogen Free and RoHS compliant.
• Energy absorption capability WTMup to 360J
• Wide operating voltage range VMACRMS 130V to 1000V
• No derating up to 85ºC ambient
• Available in tape and reel or bulk pack
额定电压DC 300 V
额定电压AC 230 V
额定电流 1 mA
绝缘电阻 1000 MΩ
电容 0.0011 µF
电路数 1
钳位电压 595 V
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压DC Max 300 V
额定电压AC Max 230 V
安装方式 Through Hole
封装 Disc 20mm
宽度 5.6 mm
高度 26.5 mm
封装 Disc 20mm
工作温度 -55℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2014/12/17
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
V230LA40AP Littelfuse 力特 | 当前型号 | 当前型号 |
V230LA40A 力特 | 类似代替 | V230LA40AP和V230LA40A的区别 |
B72220S0231K101 爱普科斯 | 功能相似 | V230LA40AP和B72220S0231K101的区别 |
