V230LS20AP

Var MOV 230VAC/300VDC 4500A 396V Thru-Hole Radial T/R

360 V 4.5 kA 变阻器 1 电路 通孔 圆片式 14mm

得捷:
VARISTOR 360V 4.5KA DISC 14MM

立创商城:
V230LS20AP

贸泽:
Varistors 230V 550pF

艾睿:
Apply different voltages to this V230LS20AP MOV from Littelfuse in order to change resistance of it. This device&s;s clamping current is 50 A and clamping voltage is 595 V. This part has a pitch of 8.5 mm. Its maximum surge current is 4500 A. This voltage dependent resistor has an operating temperature of -55 to 85 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This varistor has a voltage of 396 V. This product is 20 mm tall and 5.6 mm deep with a diameter of 17 mm. Its capacitance value is 550pF. This device is made with metal oxide technology. The maximum AC voltage rating is 230 VAC and the maximum DC voltage rating is 300 VDC.

Chip1Stop:
Var MOV 230VAC/300VDC 4500A 396V Radial T/R

Verical:
Var MOV 230VAC/300VDC 4500A 396V Thru-Hole Radial T/R
