压敏电阻产品 Varistor Products
变阻器 电路 通孔 径向
得捷:
VARISTOR 220V 22KA RADIAL
立创商城:
V25S140P
贸泽:
压敏电阻 140VAC 285J 355V CLAMP 22KAPK 25MM
艾睿:
Never worry about improper resistance being seen by your components with this V25S140P MOV from Littelfuse, it will change depending on voltages. This device&s;s clamping current is 100 A and clamping voltage is 355 V. Its maximum surge current is 22000 A. This voltage dependent resistor has an operating temperature of -55 to 85 °C. This varistor has a voltage of 240 V. This product is 28 mm long, 32.5 mm tall and 6 mm deep. The maximum AC voltage rating is 140 VAC and the maximum DC voltage rating is 180 VDC. Its capacitance value is 0.0035uF. This device is made with metal oxide technology.
Chip1Stop:
Var MOV 140VAC/180VDC 22000A 240V Radial
Verical:
Var MOV 140VAC/180VDC 22000A 242V Thru-Hole Radial Bulk
Newark:
TVS Varistor, UltraMOV™, 140 V, 180 V, UltraMOV Series, 355 V, Disc 25mm
额定电压DC 180 V
额定电压AC 140 V
电容 0.0035 µF
容差 5 %
电路数 1
钳位电压 355 V
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压DC Max 180 V
额定电压AC Max 140 V
安装方式 Through Hole
封装 Radial
长度 32.5 mm
宽度 28 mm
高度 32.5 mm
封装 Radial
工作温度 -55℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
