V250SM20

压敏电阻产品 - 表面贴装压敏电阻 Varistor Products - Surface Mount Varistors

391.5 V 6.5 kA 变阻器 1 电路 表面贴装型 圆片式，20mm，接片式 SMD

得捷:
VARISTOR 391.5V 6.5KA DISC 20MM

立创商城:
V250SM20

艾睿:
Similar to a diode this V250SM20 MOV manufactured from Littelfuse is a nonlinear component. Its maximum surge current is 6500 A. This device&s;s clamping current is 100 A and clamping voltage is 650 V. This voltage dependent resistor has an operating temperature of -40 to 85 °C. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. This device is made with metal oxide technology. This varistor has a voltage of 429 V. This product is 35 mm long, 10.5 mm tall and 26 mm deep. Its capacitance value is 0.001uF. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 330 VDC.

Chip1Stop:
Var MOV 250VAC/330VDC 6500A 429V SMD

Newark:
# LITTELFUSE  V250SM20  TVS Varistor, 250 V, 330 V, SM20 Series, 650 V, SMD, Metal Oxide Varistor MOV

Win Source:
VARISTOR 391.5V 6.5KA DISC 20MM / 391.5 V 6.5 kA Varistor 1 Circuit Surface Mount Disc 20mm, Tabbed SMD
