VISHAY VS-P105W 晶闸管, 1200 V, 60 mA, 25 A, 模块, 6 引脚
The is a 6-pin Power Module Thyristor with passivated assembled circuit elements. The VS-P100 series module has integrated power circuits consists of power thyristors and power diodes configured in a single package. With its isolating base plate, mechanical designs are greatly simplified giving advantage of reduced size.
输出电流 25.0 A
负载电流 25 A
针脚数 6
隔离电压 2.50 kV
保持电流Max 130 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
工作结温 -40℃ ~ 125℃
安装方式 Quick Connect
引脚数 6
封装 PACE-8
高度 15.5 mm
封装 PACE-8
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Bulk
制造应用 Power Management, 电机驱动与控制, 电源管理, Motor Drive & Control
RoHS标准 RoHS Compliant
含铅标准 Lead Free
