四通道高端驱动器 QUAD CHANNEL HIGH SIDE DRIVER
电源开关/驱动器 1:1 N 通道 3.5A 28-SO
得捷:
IC PWR DRIVER N-CHANNEL 1:1 28SO
艾睿:
Thanks to the high side VNQ810 power switch, developed by STMicroelectronics, you can easily switch on and off with high voltages and currents. This charge controller has 4 outputs. It features 0.16Max Ohm switch on resistance. This device has a maximum power dissipation of 6250 mW. Its maximum power dissipation is 6250 mW. This device has a supply current of 5 mA and a minimum output current of 3.5 A. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube.
安富利:
Power Switch Hi Side 3.5A 28-Pin SO Tube
Chip1Stop:
Power Switch Hi Side 3.5A 28-Pin SO Tube
Win Source:
IC DRIVER QUAD 36V 3.5A 28-SOIC
DeviceMart:
IC DRIVER QUAD 36V 3.5A 28-SOIC
电源电压DC 36.0V max
输出接口数 4
输出电流 3.50 A
供电电流 5 mA
通道数 4
漏源极电阻 160 mΩ
极性 N-Channel
耗散功率 6.25 W
漏源极电压Vds 41 V
连续漏极电流Ids 3.50 A
输出电流Max 3.5 A
输出电流Min 3.5 A
耗散功率Max 6250 mW
电源电压 5.5V ~ 36V
电源电压Max 36 V
电源电压Min 5.5 V
安装方式 Surface Mount
引脚数 28
封装 SOIC-28
封装 SOIC-28
厚度 2.65 mm
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
VNQ810 ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
VNQ81013TR 意法半导体 | 类似代替 | VNQ810和VNQ81013TR的区别 |
VNQ810P-E 意法半导体 | 功能相似 | VNQ810和VNQ810P-E的区别 |
