固定电感器
固定器
得捷:
FIXED IND 1.5UH 1.5A 126MOHM SMD
贸泽:
Fixed Inductors 1.5uH 0.126ohms 2.0A
艾睿:
This power VLS252012T-1R5N1R4 surface mount inductor from TDK is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -40 °C to 105 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This SMD inductor has a maximum DC current of 1.5Typ A with a maximum resistance of 126m Ohm. This product is 2.6 mm long, 1.2 mm tall and 2.1 mm deep. It has an inductance of 1.5u H. This device utilizes wirewound technology. Its test frequency is 1M Hz.
安富利:
Ind Power Shielded Wirewound 1.5uH 30% 1MHz 1.5A 1008 T/R
富昌:
VLS 系列 1.5 uH ±30% 1.5 A 0.126 Ohm 薄型 屏蔽 线绕电感
Verical:
Inductor Power Shielded Wirewound 1.5uH 30% 1MHz 1.5A 0.126Ohm DCR 1008 T/R
MASTER:
Inductor Power Shielded Wirewound 1.5uH 30% 1MHz 1.5A 126mOhm DCR 1008 T/R
Online Components:
Inductor Power Shielded Wirewound 1.5uH 30% 1MHz 1.5A 126mOhm DCR 1008 T/R
Electro Sonic:
Inductor Power Shielded Wirewound 1.5uH 30% 1MHz 1.5A 126mOhm DCR 1008 T/R
Win Source:
1.5μH Shielded Wirewound Inductor 1.5A 126 mOhm Max 1008 2520 Metric
额定电流 1.5 A
容差 ±30 %
电感 1.5 µH
电感公差 ±30 %
测试频率 1 MHz
电阻DC) ≤126 mΩ
工作温度Max 105 ℃
工作温度Min -40 ℃
电阻DC Max 126 mΩ
安装方式 Surface Mount
封装 1008
长度 2.5 mm
宽度 2 mm
高度 1.2 mm
封装 1008
工作温度 -40℃ ~ 105℃
产品生命周期 Not Recommended for New Designs
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8532240020
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
VLS252012T-1R5N1R4 TDK 东电化 | 当前型号 | 当前型号 |
VLS252010ET-1R5N-CA 东电化 | 类似代替 | VLS252012T-1R5N1R4和VLS252010ET-1R5N-CA的区别 |
