VNP35N07

？ OMNIFET ?:岗AUTOPROTECTED功率MOSFET ”OMNIFET”: FULLY AUTOPROTECTED POWER MOSFET

DESCRIPTION

The is a monolithic device made using SGS-THOMSON Vertical Intelligent Power M0 Technology, intended for replacement of standard power MOSFETS in DC to 50 KHz applications. Built-in thermal shut-down, linearcurrent limitation and overvoltage clamp protect the chip in harsh enviroments. Fault feedback can be detected by monitoring the voltage at the input pin.

■ LINEAR CURRENT LIMITATION

■ THERMAL SHUT DOWN

■ SHORT CIRCUIT PROTECTION

■ INTEGRATED CLAMP

■ LOW CURRENT DRAWN FROM INPUT PIN

■ DIAGNOSTIC FEEDBACK THROUGH INPUT PIN

■ ESD PROTECTION

■ DIRECT ACCESS TO THE GATE OF THE POWER MOSFET ANALOG DRIVING

■ COMPATIBLE WITH STANDARD POWER MOSFET

■ STANDARD TO-220 PACKAGE
