VISHAY VS-10MQ100NPBF 肖特基整流器, 单, 100 V, 2.1 A, DO-214AC, 2 引脚, 680 mV
The is a surface mount high performance Schottky Rectifier with guard ring for enhanced ruggedness and long term reliability and small foot print. Designed for applications requiring low forward drop and very small foot prints on PC boards.
针脚数 2
正向电压 0.85 V
热阻 80℃/W RθJA
正向电流 2.1 A
最大正向浪涌电流(Ifsm) 120 A
正向电压Max 680 mV
工作温度Max 150 ℃
工作温度Min -55 ℃
工作结温Max 150 ℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AC
长度 4.6 mm
高度 2.237 mm
封装 DO-214AC
工作温度 -55℃ ~ 150℃
产品生命周期 Obsolete
包装方式 Bulk
制造应用 Computers & Computer Peripherals, Power Management, Industrial, 电源管理, 安全, Safety, 工业, 计算机和计算机周边
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
VS-10MQ100NPBF Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
VS-10MQ100NTRPBF 威世 | 类似代替 | VS-10MQ100NPBF和VS-10MQ100NTRPBF的区别 |
