VN5160S-E 系列 单通道 5.4A 高压侧 驱动器 用于汽车应用
电源 IC,高侧电源开关,STMicroelectronics
高侧开关可在电阻、电感和电容式接地负载中安全驱动高电流。 设计用于在恶劣的汽车环境中工作,它们需要坚固、低接通电阻电源开关和准确模拟电路,用于诊断、保护和控制功能。
### 智能电源开关,STMicroelectronics
得捷:
IC PWR DRIVER N-CHANNEL 1:1 8SO
欧时:
STMicroelectronics VN5160STR-E, 单输出 负载开关集成电路, 高侧驱动器开关, 5A, 36V, 8引脚 SOIC封装
立创商城:
VN5160STR-E
贸泽:
Gate Drivers Sngl Ch HiSide Drivr
艾睿:
Connecting a load to a power supply has never been easier with this high side VN5160STR-E power switch by STMicroelectronics. This charge controller has single output. It features 0.21Max Ohm switch on resistance. This device has a supply current of 1.9 mA. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This charge controller has a minimum operating temperature of -40 °C and a maximum of 150 °C.
安富利:
IC HIGH SIDE DRIVER 8SO T/R
富昌:
VN5160S-E Series Single Channel 5.4A High Side Driver for Automotive Application
TME:
Driver; high-side switch; 5.4A; Channels:1; SO8; 4.5÷36V
儒卓力:
**HSS 160mOhm 36V SO-8 SMD **
Win Source:
IC DVR HIGHSIDE AUTO 8-SOIC
DeviceMart:
IC DVR HIGHSIDE AUTO 8-SOIC
输出接口数 1
输出电流 5.4 A
针脚数 8
输出电流Max 3.8 A
输入数 1
工作温度Max 150 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 36V
电源电压Max 41 V
电源电压Min 4.5 V
输入电压 13 V
安装方式 Surface Mount
引脚数 8
封装 SO-8
长度 5 mm
宽度 4 mm
高度 1.65 mm
封装 SO-8
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
VN5160STR-E ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
VN5160S-E 意法半导体 | 功能相似 | VN5160STR-E和VN5160S-E的区别 |
