标准LED-SMD Yellow Green 573nm
**VAOL Series SMD s**
A selection of surface mount LED solutions from VCCs extensive line of LEDs products. The VAOL series is compatible with infrared and vapor phase reflow solder process. These LEDs are available in various sizes and have a wide choice of LED emitting Colors to suit your Optoelectronics applications.
得捷:
LED YELLOW/GREEN CLEAR 2PLCC SMD
贸泽:
标准LED-SMD Yellow Green 573nm
艾睿:
LED Uni-Color Yellow Green 575nm T/R
Allied Electronics:
VAOL-S2GT4, VAOL Series Green, Yellow LED, 573 nm SMD package
Newark:
# VCC VISUAL COMMUNICATIONS COMPANY VAOL-S2GT4 LED, Green, SMD, 2.4mm, 20 mA, 2 V, 573 nm
CDI:
YELLOWISH GREEN PLCC2, 2K REEL
正向电压 2 V
波长 573 nm
发光强度 96 mcd
视角 120°
峰值波长 575 nm
测试电流 20 mA
正向电流 20 mA
正向电压Max 2.4 V
正向电流Max 50 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 100 mW
安装方式 Surface Mount
引脚数 2
封装 PLCC-2
长度 3.5 mm
宽度 2.7 mm
高度 1.9 mm
封装 PLCC-2
产品生命周期 Obsolete
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 无铅
REACH SVHC版本 2016/06/20
