RGB 1.6 x 1 mm 120° 100/180/50 mcd 透明 2/3.3/3.3 V 表面贴装 LED
Tri-Color Blue/Green/Red 468nm/518nm/632nm 6-Pin SMD T/R
得捷:
LED RGB CLEAR SMD
艾睿:
LED Tri-Color Blue/Green/Red 468nm/518nm/632nm 6-Pin SMD T/R
Allied Electronics:
RGB SMD 1.6 x 1.6 x 0.35 LED WATER CLEAR
Verical:
LED Tri-Color Blue/Green/Red 468nm/518nm/632nm 6-Pin SMD T/R
MASTER:
LED 0606 RGB
Online Components:
LED Tri-Color Blue/Green/Red 468nm/518nm/632nm 6-Pin SMD T/R
CDI:
RGB SMD 1.6 x 1.6 x 0.35 LED WATER CLEAR
Electro Sonic:
LED 0606 RGB
波长 624nm Red,525nm Green,470nm Blue
视角 120°
峰值波长 632nm Red,518nm Green,468nm Blue
耗散功率 110/110/60mW
测试电流 20 mA
正向电流 25 mA
正向电流Max 25 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 6
封装 SMD-6
宽度 1.6 mm
高度 0.35 mm
封装 SMD-6
颜色 Red, Green, Blue RGB
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8541402000
