WALSIN WR06X2401FTL 片式电阻器, 表面贴装, WR06 Series, 2.4 kohm, 75 V, 0603 [1608公制], 100 mW, ± 1%
SMD器/芯片电阻器
立创商城:
2.4kΩ ±1% 100mW
e络盟:
SMD片式电阻, 0603 [1608公制], 2.4 kohm, WR06 Series, 75 V, 厚膜, 100 mW
艾睿:
This is a WR06X2401FTL fixed single surface-mount resistor from Walsin Technology Corporation. This durable part has a power rating of 0.1 1/10 W. This product has a resistance value of 2.4K Ohm. Its temperature coefficient is ±100 ppm/°C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This device utilizes thick film technology. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep. It has a tolerance of 1%. This part has an operating temperature of -55 to 155 °C.
Verical:
Res Thick Film 0603 2.4K Ohm 1% 0.1W1/10W ±100ppm/C SMD T/R
Newark:
# WALSIN WR06X2401FTL Surface Mount Chip Resistor, WR06 Series, 2.4 kohm, 100 mW, 1%, 75 V, 0603 [1608 Metric]
额定电压DC 75.0 V
额定功率 100 mW
产品系列 WR
电阻 2.4 kΩ
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±1 %
额定电压 75 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.45 mm
封装公制 1608
封装 0603
触点材质 Tin
温度系数 ±100 ppm/℃
包装方式 Tape & Reel TR
最小包装 5000
制造应用 工业, Industrial, Portable Devices, 便携式器材, 电源管理, Power Management, 消费电子产品, Consumer Electronics
RoHS标准
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
WR06X2401FTL Walsin Technology 台湾华科 | 当前型号 | 当前型号 |
RC0603FR-072K4L 国巨 | 功能相似 | WR06X2401FTL和RC0603FR-072K4L的区别 |
ERJU03F2401V 松下 | 功能相似 | WR06X2401FTL和ERJU03F2401V的区别 |
MCWR06X2401FTL Multicomp | 功能相似 | WR06X2401FTL和MCWR06X2401FTL的区别 |
