WALSIN WR04X7500FTL 片式电阻器, 表面贴装, WR04 Series, 750 ohm, 50 V, 0402 [1005公制], 62.5 mW, ± 1%
SMD器/芯片电阻器
立创商城:
750Ω ±1% 62.5mW
得捷:
RES 750 OHM 1% 1/16W 0402
e络盟:
SMD片式电阻, 0402 [1005公制], 750 ohm, WR04 Series, 50 V, 厚膜, 62.5 mW
艾睿:
The WR04X7500FTL fixed single surface-mount resistor from Walsin Technology Corporation makes it easy to add resistors to your circuit board. This part has a power rating of 0.063 1/16 W. This product has a resistance value of 750 Ohm. Its temperature coefficient is ±100 ppm/°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This device utilizes thick film technology. It has a tolerance of 1%. This part has an operating temperature of -55 to 155 °C. This product is 1 mm long, 0.35 mm tall and 0.5 mm deep.
Verical:
Res Thick Film 0402 750 Ohm 1% 0.063W1/16W ±100ppm/C SMD T/R
Newark:
# WALSIN WR04X7500FTL Surface Mount Chip Resistor, WR04 Series, 750 ohm, 62.5 mW, 1%, 50 V, 0402 [1005 Metric]
额定电压DC 50.0 V
额定功率 62.5 mW
产品系列 WR
电阻 750 Ω
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±1 %
额定电压 50 V
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.35 mm
封装公制 1005
封装 0402
触点材质 Tin
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Cut Tape CT
最小包装 10000
制造应用 Power Management, 工业, Industrial, 便携式器材, Consumer Electronics, Portable Devices, 电源管理, 消费电子产品
RoHS标准
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
WR04X7500FTL Walsin Technology 台湾华科 | 当前型号 | 当前型号 |
MCWR04X7500FTL Multicomp | 类似代替 | WR04X7500FTL和MCWR04X7500FTL的区别 |
RC0402FR-07750RL 国巨 | 功能相似 | WR04X7500FTL和RC0402FR-07750RL的区别 |
MC00625W04021750R Multicomp | 功能相似 | WR04X7500FTL和MC00625W04021750R的区别 |
