WALSIN WR06X2202FTL 片式电阻器, 表面贴装, WR06系列, 22 kohm, 75 V, 0603 [1608公制], 100 mW, ± 1%
SMD器/芯片电阻器
得捷:
RES 22K OHM 1% 1/10W 0603
立创商城:
22kΩ ±1% 100mW
e络盟:
SMD片式电阻, 0603 [1608公制], 22 kohm, WR06 Series, 75 V, 厚膜, 100 mW
艾睿:
The WR06X2202FTL fixed single surface-mount resistor from Walsin Technology Corporation makes it easy to add resistors to your circuit board. This product has a resistance value of 22K Ohm. This durable part has a power rating of 0.1 1/10 W. Its temperature coefficient is ±100 ppm/°C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 1%. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep. This part has an operating temperature of -55 to 155 °C. This device utilizes thick film technology.
Verical:
Res Thick Film 0603 22K Ohm 1% 0.1W1/10W ±100ppm/C Pad SMD T/R
Newark:
# WALSIN WR06X2202FTL Surface Mount Chip Resistor, WR06 Series, 22 kohm, 100 mW, 1%, 75 V, 0603 [1608 Metric]
Win Source:
RES 22K OHM 1% 1/10W 0603 / 22 kOhms ±1% 0.1W, 1/10W Chip Resistor 0603 1608 Metric Thick Film
额定电压DC 75.0 V
额定功率 100 mW
产品系列 WR
电阻 22 kΩ
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±1 %
额定电压 75 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.45 mm
封装公制 1608
封装 0603
触点材质 Tin
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 5000
制造应用 工业, Industrial, Portable Devices, 便携式器材, 电源管理, Power Management, 消费电子产品, Consumer Electronics
RoHS标准
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
WR06X2202FTL Walsin Technology 台湾华科 | 当前型号 | 当前型号 |
RC0603FR-0722KL 国巨 | 功能相似 | WR06X2202FTL和RC0603FR-0722KL的区别 |
CR0603-FX-2202ELF 伯恩斯 | 功能相似 | WR06X2202FTL和CR0603-FX-2202ELF的区别 |
RC0603FR-1022KL 国巨 | 功能相似 | WR06X2202FTL和RC0603FR-1022KL的区别 |
