XPGBWT-L1-0000-00G51

CREE  XPGBWT-L1-0000-00G51  发光二极管, 高亮, 冷白色, 130LM, 整卷

The XLAMP XP-G2 series is built on the SC³ technology platform, delivers up to 20% more lumens per watt and 2.5 times the lumens-per-dollar over the original XP-G, lowering system cost up to 57%. The new XP-G2 is optically compatible with the original XP-G, providing drop-in-ready performance enhancements to shorten the LED fixture design cycle and improve time to market. Combining high light output, reliability and efficacy, XP-G2 is optimized for directional, high-lumen applications, from indoor and outdoor to portable and lamp retrofits.

.

Available in white, outdoor white and 80-, 85- and 90-CRI white

.

ANSI-compatible chromaticity bins

.

Binned at 85°C

.

1500mA Maximum drive current

.

4°C/W Low thermal resistance

.

115° Wide viewing angle

.

Unlimited floor life at

.

Reflow solderable, JEDEC J-STD-020C

.

Electrically neutral thermal path

.

REACH compliant

.

UL recognized component E349212
