CREE XPEBRD-L1-R250-00601 高亮发光二极管, XLamp XP-E2系列, 红色, 130 °, 62 lm, 700 mA
The XLamp XP-E2 series delivers high performance and lower system cost to XLamp XP LED designs. Built on Cree"s revolutionary SC³ Technology™ Platform, XP-E2 LEDs deliver higher lumens per watt and lumens per dollar to lower system costs for existing XP-E designs. XP-E2 LEDs leverage the same XP footprint and are optically compatible with the original XP-E LED, providing drop-in-ready performance enhancements to shorten design cycle and improve customer time-to-market. Characterized and binned at 85°C, the XLamp® XP-E2 White LED delivers up to 20% more lumens-per-watt and double the lumens-per-dollar compared to the original XP-E LED. The XP-E2 White LED can enable a broad range of high-lumen applications, from indoor and outdoor to portable and lamp retrofits. The XLamp XP-E2 Colour LEDs deliver up to 88% higher maximum light output compared to alternative high-power colour LEDs, enabling lighting manufacturers to more cost-effectively address a wide spectrum of applications
正向电压 2.2 V
波长 625nm 620nm ~ 630nm
视角 130°
耗散功率 3 W
热阻 5 ℃/W
测试电流 350 mA
正向电流Max 700 mA
安装方式 Surface Mount
引脚数 3
封装 SMD-2
宽度 3.45 mm
封装 SMD-2
颜色 Red
外观颜色 Transparent
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 LED Lighting, 车用, 发光二极管照明, Automotive
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
