XC3S700A-5FG484C

FPGA Spartan -3A Family 700K Gates 13248 Cells 770MHz 90nm Technology 1.2V 484Pin FBGA

* Very low cost, high-performance logic solution for high-volume, cost-conscious applications * Dual-range VCCAUX supply simplifies 3.3V-only design * Suspend, Hibernate modes reduce system power * Multi-voltage, multi-standard SelectIO™ interface pins * Up to 502 I/O pins or 227 differential signal pairs * LVCMOS, LVTTL, HSTL, and SSTL single-ended I/O * 3.3V, 2.5V, 1.8V, 1.5V, and 1.2V signaling * Selectable output drive, up to 24 mA per pin * QUIETIO standard reduces I/O switching noise * Full 3.3V ± 10% compatibility and hot swap compliance * 640+ Mb/s data transfer rate per differential I/O * LVDS, RSDS, mini-LVDS, HSTL/SSTL differential I/O with integrated differential termination resistors * Enhanced Double Data Rate DDR support * DDR/DDR2 SDRAM support up to 400 Mb/s * Fully compliant 32-/64-bit, 33/66 MHz PCI® technology support * Abundant, flexible logic resources * Densities up to 25,344 logic cells, including optional shift register or distributed RAM support * Efficient wide multiplexers, wide logic * Fast look-ahead carry logic * Enhanced 18 x 18 multipliers with optional pipeline * IEEE 1149.1/1532 JTAG programming/debug port * Hierarchical SelectRAM™ memory architecture * Up to 576 Kbits of fast block RAM with byte write enables for processor applications * Up to 176 Kbits of efficient distributed RAM * Up to eight Digital Clock Managers DCMs * Clock skew elimination delay locked loop * Frequency synthesis, multiplication, division * High-resolution phase shifting * Wide frequency range 5 MHz to over 320 MHz * Eight low-skew global clock networks, eight additional clocks per half device, plus abundant low-skew routing * Configuration interface to industry-standard PROMs * Low-cost, space-saving SPI serial Flash PROM * x8 or x8/x16 BPI parallel NOR Flash PROM * Low-cost ® Platform Flash with JTAG * Unique Device DNA identifier for design authentication * Load multiple bitstreams under FPGA control * Post-configuration CRC checking * Complete Xilinx ISE® and WebPACK™ development system software support plus Spartan-3A Starter Kit * MicroBlaze™ and PicoBlaze™ embedded processors * Low-cost QFP and BGA packaging, Pb-free options * Common footprints support easy density migration * Compatible with select Spartan-3AN nonvolatile FPGAs * Compatible with higher density Spartan-3A DSP FPGAs
