X9C102PIZ

INTERSIL  X9C102PIZ  非易失性数字电位器, 1 kohm, 单, 3线, 串行, 线性, ± 20%, 4.5 V

The is a Digitally Controlled Potentiometer consists of a resistor array, wiper switches, a control section and non-volatile memory. The wiper position is controlled by a three-wire interface. The potentiometer is implemented by a resistor array composed of 99 resistive elements and a wiper switching network. Between each element and at either end are tap points accessible to the wiper terminal. The position of the wiper element is controlled by the CS, U/D and INC inputs. The position of the wiper can be stored in non-volatile memory and then be recalled upon a subsequent power-up operation. The device can be used as a three-terminal potentiometer or as a two-terminal variable resistor in a wide variety of applications.

.

Solid-state potentiometer

.

99 Resistive elements - Temperature compensated

.

Low power CMOS - 3mA Maximum active current and 750µA maximum standby current

.

High reliability - 100000 Data changes per bit endurance
