集管和线壳 MIL BoxType Plug 60P Straight 1Polarize
针座 通孔 60 位置 0.100"（2.54mm）
得捷:
CONN HEADER VERT 60POS 2.54MM
贸泽:
集管和线壳 MIL BoxType Plug 60P Straight 1Polarize
Allied Electronics:
Headers; MIL BoxType Plug 60P Straight 1Polarize
Chip1Stop:
Conn Shrouded Header PL 60 POS 2.54mm Solder ST Thru-Hole
Newark:
# OMRON ELECTRONIC COMPONENTS XG4C-6031 Wire-To-Board Connector, 2.54 mm, 60 Contacts, Header, XG4 Series, Through Hole, 2 Rows
MASTER:
Conn Shrouded Header PL 60 POS 2.54mm Solder ST Thru-Hole
Online Components:
Conn Shrouded Header PL 60 POS 2.54mm Solder ST Thru-Hole
Electro Sonic:
Conn Shrouded Header PL 60 POS 2.54mm Solder ST Thru-Hole
触点数 60
极性 Male
触点电镀 Gold
额定电流 3 A
绝缘电阻 >1000MΩ @500VDC
排数 2
针脚数 60
额定电流Max 3 A
额定电压Max 300 VAC
额定电压 300 V
安装方式 Through Hole
长度 83.5 mm
宽度 8.5 mm
高度 9 mm
颜色 Black
触点材质 Brass
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Tray
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536694040
