XG4A-3431

DIP 34P 间距2.54mm

Conn Ejector Header PL 34 POS 2.54mm Solder ST Thru-Hole

欧时:
MIL Plugs with Long Locks; straight DIP

立创商城:
2.54mm 每排P数:17 排数:2

得捷:
CONN HEADER VERT 34POS 2.54MM

艾睿:
Mount this ejector XG4A-3431 header connector from Omron on a jumper post on your PCB to support physical configuration options. This PL connector&s;s 34 contacts that are made out of brass and plated with gold over nickel. This is a 2-row connector. It has a plug type gender. Its pitch is 2.54 mm. It has a straight body orientation. It has a maximum voltage rating of 300 VAC. This device has a maximum current rating of 3 A. This connector has an operating temperature of -55 to 105 °C. This product is 62.5 mm long, 27 mm tall and 8.5 mm deep. It uses the solder termination method. XG4A-3431 is housed in black polybutylene terephthalate.

Allied Electronics:
Headers; Plug Long Lock 34P Straight 1Polarize

Chip1Stop:
Conn Ejector Header PL 34 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Ejector Header PL 34 POS 2.54mm Solder ST Thru-Hole

Newark:
# OMRON ELECTRONIC COMPONENTS  XG4A-3431  Wire-To-Board Connector, 2.54 mm, 34 Contacts, Header, XG4 Series, Through Hole, 2 Rows

MASTER:
Conn Ejector Header PL 34 POS 2.54mm Solder ST Thru-Hole

Online Components:
Conn Ejector Header PL 34 POS 2.54mm Solder ST Thru-Hole

Electro Sonic:
Conn Ejector Header PL 34 POS 2.54mm Solder ST Thru-Hole

Win Source:
CONN HEADER VERT 34POS 2.54MM / Connector Header Through Hole 34 position 0.100" 2.54mm
