XBee-PRO ZB ZigBee RF ModuleThe XBee-PRO ZB ZigBee RF module operates in the 2.4GHz ISM Band and allows the formation of a mesh network. With its high receiver sensitivity it can provide line-of-sight communication for up to 750m.Carrier frequency: 2.4GHz ISM band with 14 channels RF Power Output: +10dBm Receiver Sensitivity: -102dBm @ 1% PER Interference control: Direct Sequence Spread Spectrum DSSS, Packet Retry/Acknowledgement OTA Date Rate: up to 250kbps Host communication: serial UART with RTS/CTS flow control Supported network topologies: Point-to-Point, Point-to-Multipoint, Peer-to-Peer & Mesh Self-routing, self-healing and fault-tolerant mesh networking AES-128 encryption Antenna: Whip RS 667-2991, External via U.FL RS 667-2998, PCB RS 771-6358, RPSMA RS 667-2989 4 channel 10-bit ADC 16 x GPIO pins Power supply: +3.0V to +3.4Vdc Operating temperature range: -40 to +85°C Dimensions: 24.4 x 33 x 3mm DIP Applications: Wireless sensor networks, communication for the Internet of Things IoT ### 注ZB and ZNet 2.5 firmware are similar in nature, but not over-the-air compatible. Devices running ZNet 2.5 firmware cannot communicate with devices running ZB firmware.### 认可FCC, IC, ETSI, C-TICK, Japan### WPAN IEEE 802.15.4 - Digi International
is manufactured by and is categorized in the RF Transceiver Modules category. XBP24-Z7SIT-004J is described as RF TXRX MODULE 802.15.4 RP-SMA. Perfect Parts is a supplier of RF/IF and RFID and other Semiconductors.
欧时:
XBee-PRO ZB ZigBee RF ModuleThe XBee-PRO ZB ZigBee RF module operates in the 2.4GHz ISM Band and allows the formation of a mesh network. With its high receiver sensitivity it can provide line-of-sight communication for up to 750m.Carrier frequency: 2.4GHz ISM band with 14 channels RF Power Output: +10dBm Receiver Sensitivity: -102dBm @ 1% PER Interference control: Direct Sequence Spread Spectrum DSSS, Packet Retry/Acknowledgement OTA Date Rate: up to 250kbps Host communication: serial UART with RTS/CTS flow control Supported network topologies: Point-to-Point, Point-to-Multipoint, Peer-to-Peer & Mesh Self-routing, self-healing and fault-tolerant mesh networking AES-128 encryption Antenna: Whip RS 667-2991, External via U.FL RS 667-2998, PCB RS 771-6358, RPSMA RS 667-2989 4 channel 10-bit ADC 16 x GPIO pins Power supply: +3.0V to +3.4Vdc Operating temperature range: -40 to +85°C Dimensions: 24.4 x 33 x 3mm DIP Applications: Wireless sensor networks, communication for the Internet of Things IoT### 注ZB and ZNet 2.5 firmware are similar in nature, but not over-the-air compatible. Devices running ZNet 2.5 firmware cannot communicate with devices running ZB firmware.### 认可FCC, IC, ETSI, C-TICK, Japan
贸泽:
Zigbee / 802.15.4 Modules XBee-PRO ZB, 10mW RPSMA ant, 250K bps
艾睿:
ZIGBEE / 802.15.4 MODULES XBEE-PRO ZB, 10MW RPSMA ANT, 250K BPS
Verical:
ZIGBEE / 802.15.4 MODULES XBEE-PRO ZB, 10MW RPSMA ANT, 250K BPS
