YC164-JR-07330KL

电阻器网络与阵列

器网络与阵列

得捷:
RES ARRAY 4 RES 330K OHM 1206

艾睿:
Conserve space and power by adopting this YC164-JR-07330KL resistor array from Yageo, allowing multiple configurations of resistors to be downsized into an IC. This product&s;s 4 resistors have a value of 330K Ohm. Its temperature coefficient is ±200 ppm/°C. This dependable part has a power rating per resistor of 0.063 1/16 W. It has 8 terminals. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This device utilizes thick film technology. It has a tolerance of 5%. The YC164-JR-07330KL part has a convex termination style. This product&s;s terminal pitch is 0.8 mm. This part has an operating temperature of -55 to 155 °C.

安富利:
Res Thick Film Array 330K Ohm 5% ±200ppm/°C ISOL Molded 8-Pin 12064 X 0603 Convex SMD Paper T/R

Chip1Stop:
Res Thick Film Array 330K Ohm 5% ±200ppm/℃ ISOL Molded 8-Pin 12064 X 0603 Convex SMD T/R

Verical:
Res Thick Film Array 330K Ohm 5% ±200ppm/C ISOL Epoxy 8-Pin 12064 X 0603 Convex SMD Automotive T/R

儒卓力:
**CN1206R4 330K 5% 0,063W CONVEX **
