YAGEO PHYCOMP YC248-JR-0722RL 电阻阵列, 8电阻, 0616, 5%, 22R
器网络与阵列
得捷:
RES ARRAY 8 RES 22 OHM 1606
立创商城:
22Ω ±5%
贸泽:
电阻器网络与阵列 22 5% CONVEX SQUARE 8X0402
艾睿:
Conserve space and power by adopting this YC248-JR-0722RL resistor array from Yageo, allowing multiple configurations of resistors to be downsized into an IC. This product&s;s 8 resistors have a value of 22 Ohm. Its temperature coefficient is ±200 ppm/°C. This dependable part has a power rating per resistor of 0.063 1/16 W. It has 16 terminals. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This device is made with thick film technology. This product is 4 mm long, 0.45 mm tall and 1.6 mm deep. It has a tolerance of 5%. The YC248-JR-0722RL part has a convex termination style. This part has an operating temperature of -55 to 155 °C. This product&s;s terminal pitch is 0.5 mm.
安富利:
Res Thick Film Array 22 Ohm 5% ±200ppm/°C ISOL Molded 16-Pin 16068 X 0602 Convex SMD Paper T/R
Chip1Stop:
Res Thick Film Array 22 Ohm 5% ±200ppm/ÂÂ℃ ISOL Molded 16-Pin 16068 X 0602 Convex SMD Paper T/R
Verical:
Res Thick Film Array 22 Ohm 5% ±200ppm/C ISOL Epoxy 16-Pin 16068 X 0602 Convex SMD Automotive T/R
Newark:
# YAGEO PHYCOMP YC248-JR-0722RL RESISTOR ARRAY, 8 RES, 0616, 5%, 22R
儒卓力:
**CN1506R8 22R 5% 0,063W CONVEX **
触点数 16
额定电压DC 50.0 V
容差 ±5 %
额定功率 0.0625 W
电路数 8
针脚数 16
耗散功率 0.063 W
产品系列 YC
电阻 22 Ω
阻值偏差 ±5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
引脚数 16
封装 SMD
长度 4 mm
宽度 1.6 mm
高度 0.45 mm
封装 SMD
工作温度 -55℃ ~ 155℃
温度系数 ±200 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 5000
制造应用 DDRAM,SDRAM
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
