YC124-JR-0739RL

电阻器网络与阵列

器网络与阵列

得捷:
RES ARRAY 4 RES 39 OHM 0804

立创商城:
39Ω ±5% 0402x4

艾睿:
Create more space in your circuit design by using this YC124-JR-0739RL resistor array developed by Yageo that packs multiple resistors into one IC chip. This product&s;s 4 resistors have a value of 39 Ohm. This dependable part has a power rating per resistor of 0.063 1/16 W. Its temperature coefficient is ±200 ppm/°C. It has 8 terminals. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. The YC124-JR-0739RL part has a convex termination style. This part has an operating temperature of -55 to 155 °C. This product&s;s terminal pitch is 0.5 mm. This product is 2 mm long, 0.45 mm tall and 1 mm deep. This device is made with thick film technology. It has a tolerance of 5%.

安富利:
Array Chip Resistor Thick Film 39Ohm 5% ISOL Molded 8-Pin 0804 Convex Paper T/R

富昌:
YC124 Series 4 Elements 39 Ω ±5 % 0402 x4 Case SMT Chip Resistor Network

TME:
Resistor network: Y; 39Ω; SMD; 0804; No.of resistors:4; 63mW; ±5%

儒卓力:
**CN0804R4 39R 5% 0,063W CONVEX **
