YC164-JR-071KL

YAGEO  YC164-JR-071KL  电阻阵列, 隔离式, 4X, 1KΩ, 5%, SMD

器网络与阵列

得捷:
RES ARRAY 4 RES 1K OHM 1206

欧时:
Resistor Thick Film Array 1K 5%

立创商城:
1kΩ ±5% 0603x4

贸泽:
Resistor Networks & Arrays Resistor Networks SQUARE 4x0603

艾睿:
Pack multiple resistors into a single chip with this YC164-JR-071KL resistor array from Yageo. Its temperature coefficient is ±200 ppm/°C. This product&s;s 4 resistors have a value of 1K Ohm. This dependable part has a power rating per resistor of 0.063 1/16 W. It has 8 terminals. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 5%. This device utilizes thick film technology. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This part has an operating temperature of -55 to 155 °C. This product&s;s terminal pitch is 0.8 mm. The YC164-JR-071KL part has a convex termination style.

Chip1Stop:
Res Thick Film Array 1K Ohm 5% ±200ppm/℃ ISOL Molded 8-Pin 12064 X 0603 Convex SMD T/R

TME:
Resistor network: Y; 1kΩ; SMD; 1206; No.of resistors:4; 63mW; ±5%

Verical:
Res Thick Film Array 1K Ohm 5% ±200ppm/C ISOL Epoxy 8-Pin 12064 X 0603 Convex SMD Automotive T/R

Newark:
# YAGEO  YC164-JR-071KL  Fixed Network Resistor, Isolated, 1 kohm, 50 V, 4 Elements, Isolated, 0603 [1608 Metric], 62.5 mW

儒卓力:
**CN1206R4 1K 5% 0,063W CONVEX **
