基本/快动开关 BASIC SPNO15A@250VAC PIN PLUN
MICRO SWITCH™ Basic Switches: BZ Series, Single Pole Double Throw SPDT, 15 A at 125 Vac, Overtravel Plunger Actuator, 2,5 N - 3,61 N [9 - 13 oz] Operating Force, Silver Contacts, Screw Termination
Product Highlights
Accepted world-wide standard "Large Basic" switch
Low operating force and differential travel
Long mechanical life up to 20,000,000 cycles at 95% survival
Elongated mounting hole for easier, more accurate mounting
Current rating ranges from 15 A to 25 A
Choice of actuation, termination and operating characteristics
Potential Applications:
Irrigation systems
Semi-trailer trucks
Timing devices
Office equipment
Test instruments
Medical/dental equipment
HVAC equipment
Manually operated devices
Valves
接触器类型 Pin Plunger
触点类型 SP-NO
额定电流Max 15A @480VAC
额定功率Max 372.85 VA
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压DC Max 250 V
额定电压AC Max 480 V
安装方式 Quick Connect, Chassis
高度 32.94 mm
触点材质 Silver
材质 Plastic
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536509040
