Y4053500R000J0L

VISHAY FOIL RESISTORS  Y4053500R000J0L  微调电位器, 高精密, 金属箔, 500R, 5%

Vishay Foil precision trimmers have the Bulk Metal® Foil resistive element which possesses a unique inherent temperature and load life stability. Plus, their advanced virtually back lash-free adjustment mechanism makes them easy to set quickly and accurately and keeps the setting exactly on target.

.

*

Features

* **Temperature Coefficient of Resistance TCR: ±10 ppm/°C. –55 °C to +150°C ref. at +25°C; Through the Wiper 3; ±25 ppm/°C**

* **A Smooth and Unidirectional Resistance with Leadscrew Adjustment**

* **Load Life Stability: 0.1% Typical ?R, 1.0% Maximum ?R Under Full Rated Power at +85°C for 10 000 Hours**

* **Settability: 0.05% Typical; 0.1% Maximum**

* **Setting Stability: 0.1% Typical; 0.5% Maximum, DSS**

* **Power Rating: 0.25 W at + 85°C**

* **Resistance Range: 5 Ω to 10 kΩ**

* **Tolerance: ±5 %, ±10%**

* **Electrostatic Discharge ESD Up to 25 000 V**

* **Terminal Finish: Gold Plated
