ZX40E30A01

MICRO SWITCH™ Sealed Subminiature Basic Switches: ZW Series, Single Pole Normally Closed SPNC, 5A 125/250VAC, ENEC 6A 250, 19,4mm [0.76in] Standard Straight Lever Actuator, 95g [3.35 oz] Maximum Operating Force, 800mm [31.5in] Lead Wire Termination 20 Gage Side Exit Plunger End, Red Normally Closed Lead Wire, Sealed to IP67, UL, cUL, ENEC, CQC

ZX Series, Subminiature Basic Switch, SPDT, 125 VAC Voltage Rating, 3 A

.

* ZM:** Subminiature, low cost, integral levers available; ** CE:** 61058-1, ** UL:** E12252, ** CSA:** 212438\. ** ZX:** Sub-subminiature, Low Cost, Integral Levers Available; ** CE:** 61058-1, ** UL:** E12252, ** CSA:** 212438\. ** ZV:** Subminiature, Low Cost, Snap-On Levers Available; ** CE:** 61058-1, ** UL/c-UL:** E12252. ** ZW:** Sealed ZV Switch Style; ** CE:** 61058-1, ** UL/c-UL:** E12252, ** ENEC, SE/0145-3** .

** Features**

* Various Voltage and Current Ratings

* Straight, Roller, Simulated Roller, Special Actuators

* Variety of Integral and Snap-On Actuators

* Solder, PCB Straight and Angled, Quick Connect, Special Terminations

** Specifications

**

* Operating Temperature: –13° to +185°F
