MICRO SWITCH™ Subminiature Basic Switches: ZM1 Series, Single Pole Single Throw - Normally Closed SPST-NC, 16.1A 125/250VAC, ENEC 6A 125/250, Additional ENEC Coverage @ 3A Inductive 125/250, 16,7mm [0.66in] Short Straight Lever Actuator, 355g [12.52 oz] Maximum Operating Force, Solder Termination, UL, cUL, ENEC, CQC
MICRO SWITCH™ Subminiature Basic Switches: ZM1 Series, Single Pole Single Throw - Normally Closed SPST-NC, 16.1 A 125/250 Vac, ENEC 6 A 125/250, Additional ENEC Coverage @ 3 A Inductive 125/250, 16,7 mm [0.66 in] Short Straight Lever Actuator, 355 g [12.52 oz] Maximum Operating Force, Solder Termination, UL, cUL, ENEC, CQC
Product Highlights
Subminiature: 9,0 mm H x 6,4 mm W x 19,8 mm L [0.36 in H x 0.25 in W x 0.78 in L]
Choice of low energy or power duty electrical ratings gold-plated or silver contacts
Single pole double throw SPDT circuitry or single pole single throw SPST circuitry available
Choice of 0.1 A or 5 A ratings
Choice of actuation, termination and operating characteristics
Polycarbonate housing material
IP67 sealed construction available
Potential Applications:
Appliances
Vending machines
Timing devices
Office equipment
Computer/business equipment
Test instruments
Medical/dental equipment
Communications equipment
HVAC equipment
Manually operated devices
Valves
