AC-DC Power Supply Dual-OUT 5V/24V 5A/9A 225W 15Pin
开放框架 AC DC 转换器 输出 5V 24V - - 5A，9A 85 ~ 265 VAC 输入
得捷:
AC/DC CONVERTER 5V 24V 225W
艾睿:
With this ZWD225PAF0524 AC to DC power supply from TDK-Lambda your electronic device will be able to operate by using direct current instead of alternating current. It has a voltage of 5|24 V and maximum output power of 225 W. This part&s;s 2 outputs can handle a current up to 5|9 A. This part has a minimum operating temperature of -10 °C and a maximum of 70 °C.
Allied Electronics:
Power Supply; AC-DC; 225W225W85265VAC5V, 5A, 24V, 9A
额定功率 225 W
输出接口数 2
输出功率 225 W
隔离电压 3 kV
输入电压DC Max 370 V
输入电压DC Min 120 V
输入电压AC Max 265 V
输入电压AC Min 85 V
输出电流Max 5A, 9A
输入电流Min 2.81 A
额定功率Max 225 W
工作温度Max 70 ℃
工作温度Min -10 ℃
输入电压 85VAC ~ 265VAC
安装方式 Chassis
引脚数 15
工作温度 -10℃ ~ 70℃
产品生命周期 Active
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
