ZX10C10A01

MICRO SWITCH™ Subminiature Basic Switches: ZM Series, Extended Mechanical Life, Single Pole Double Throw SPDT, 5A 125/250VAC, 18mm [0.71in] Standard Simulated Roller Lever Actuator, 146g [5.15 oz] Maximum Operating Force, Quick Connect Termination, UL, cUL, CE, CQC

MICRO SWITCH™ Subminiature Basic Switches: ZM Series, Extended Mechanical Life, Single Pole Double Throw SPDT, 5 A 125/250 Vac, 18 mm [0.71 in] Standard Simulated Roller Lever Actuator, 146 g [5.15 oz] Maximum Operating Force, Quick Connect Termination, UL, cUL, CE, CQC

Product Highlights

Subminiature: 6,5 mm H x 5,7 mm W x 12,7 mm L [0.26 in H x 0.22 in W x 0.50 in L]

Choice of low energy or power duty electrical ratings gold-plated or silver contacts

Single pole double throw SPDT circuitry or single pole single throw SPST circuitry available

Choice of 0.1 A or 3 A ratings

Choice of actuation, termination and operating characteristics

Polybutylene terephthalate housing material

Potential Applications:

Appliances

Vending machines

Timing devices

Office equipment

Computer/business equipment

Test instruments

Medical/dental equipment

Communications equipment

HVAC equipment

Manually operated devices

Valves
