ZHR-8

JST JAPAN SOLDERLESS TERMINALS  ZHR-8  线至板连接器, ZH系列, 8 触点, 插座, 1.5 mm, 压接, 1 排

1.5 mm ZH 系列外壳

1.5 mm 节距 JST ZH 外壳的设计可通过使用保留标枪提供触点锁定的目视确认。

### 注

有关 ZH 系列外壳的压接触点，请参见典型库存号 762-0759。

有关预接线触点，请参见典型库存号 820-1630。

### 认可

UL 认证 E60389

CSA 认证 LR20812

TUV 认证 R9351092

欧时:
### 1.5 mm JST ZH 连接器系列外壳1.5 mm 节距 JST ZH 外壳的设计可通过使用保留标枪提供触点锁定的目视确认。### 注有关 ZH 系列外壳的压接触点，请参见典型库存号 762-0759。 有关预接线触点，请参见典型库存号 820-1630。### 认可UL 认证 E60389 CSA 认证 LR20812 TUV 认证 R9351092### 1.5 mm 线到板 - JST ZH 连接器JSTZH 连接器系列是紧凑型 1.5 mm 节距薄型线到板系统。 ZH 系列厚度为 3.5 mm，顶部插入类型的板上方高度为 5.6mm，侧面接入类型为 3.7 mm，在各种应用中均可节省空间。

得捷:
CONN RCPT HSG 8POS 1.50MM

立创商城:
1.5mm 1x8P

艾睿:
This ZHR-8 discrete wire housing from JST Corporation is designed for both small electronic devices as well as larger power applications. This RCP connector has 8 RCP contacts. This is a 1-row connector. It has a straight body orientation. Its pitch is 1.5 mm. It has a receptacle type gender. It has a maximum voltage rating of 50 VDC|50VAC. This device has a maximum current rating of 1 A. This rectangle connector has an operating temperature of -25 to 85 °C. Its wire is 26-32 AWG. This product is 13.5 mm long, 3.4 mm tall and 4.8 mm deep. ZHR-8 is housed in white polyamide 6/6.

Chip1Stop:
Conn Housing RCP 8 POS 1.5mm Crimp ST Cable Mount Bag

TME:
Plug; wire-board; female; ZH; 1.5mm; PIN:8; w/o contacts; for cable

Verical:
Conn Housing RCP 8 POS 1.5mm Crimp ST Cable Mount White Bag

Newark:
# JST JAPAN SOLDERLESS TERMINALS  ZHR-8  Wire-To-Board Connector, ZH Series, Crimp, Receptacle, 8, 1.5 mm, Tin Plated Contacts

CDI:
Housing, 8Circuit, 1.5mmPitch
