1W,ZM47xx 系列,Vishay Semiconductor### 齐纳二极管,Vishay Semiconductor
General-purpose use in AC-to-DC bridge full wave rectification for Monitor, TV, Printer, Switching Mode Power Supply, Adapter, Audio equipment, and Home Appliances applications.
**Features:
**
* Silicon Planar Power Zener Diodes
* Standard Zener Voltage Tolerance Is ±5%
* Diodes Are Also Available in Mini-MELF Case with the Type Designation TZM5221 ... TZM5267, SOT23 Case with the Type Designations MMBZ5225 ... MMBZ5267 and SOD123 Case with the Types Designations MMSZ5225 ... MMSZ5267
* Lead Pb-Free Component
* Component in Accordance to RoHS 2002/95/EC and WEEE 2002/96/EC
**Applications:
**
* Voltage Stabilization
容差 ±5 %
击穿电压 15.0 V
耗散功率 1 W
热阻 170K/W RθJA
测试电流 17 mA
稳压值 15 V
额定功率Max 1 W
工作温度Max 175 ℃
工作温度Min -65 ℃
工作结温Max 150 ℃
耗散功率Max 1000 mW
安装方式 Surface Mount
引脚数 2
封装 DO-213AB-2
长度 5.2 mm
宽度 2.6 mm
高度 2.6 mm
封装 DO-213AB-2
工作温度 175 ℃
产品生命周期 Obsolete
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ZM4744A-GS08 Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
ZMY15-GS08 威世 | 类似代替 | ZM4744A-GS08和ZMY15-GS08的区别 |
BZG03C18TR 威世 | 功能相似 | ZM4744A-GS08和BZG03C18TR的区别 |
BZG03C10TR 威世 | 功能相似 | ZM4744A-GS08和BZG03C10TR的区别 |
