ZF5S-30-01-T-WT-TR

Conn FFC Connector SKT 30POS 0.5mm Solder RA SMD T/R

* Horizontal orientation * Surface mount

欧时:
ZIF Conn. for FFC 0.50 mm .0197"

得捷:
CONN FFC BOTTOM 30POS 0.5MM R/A

艾睿:
Space can be a limiting factor when designing electronics. Samtec&s;s ffc connector ZF5S-30-01-T-WT-TR flexible flat cable can help you fit more transmission lines onto a flat, space-saving cable. This socket type connector&s;s 30 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a right angle body orientation. Its pitch is 0.5 mm. This is a 1-row connector. This device has a maximum current rating of 1.4 A/contact. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. ZF5S-30-01-T-WT-TR is housed in black liquid crystal polymer. This flexible flat cable has an operating temperature of -55 to 105 °C. It uses the solder termination method. This product is 20.65 mm long, 2.1 mm tall and 5.66 mm deep.

安富利:
Conn FFC Connector SKT 30 POS 0.5mm Solder RA SMD T/R

Chip1Stop:
Conn FFC Connector SKT 30 POS 0.5mm Solder RA SMD T/R

Verical:
Conn FFC Connector SKT 30 POS 0.5mm Solder RA SMD T/R
