ZXMP6A13FQTA 编带
P-Channel 60 V 400 mOhm Surface Mount Enhancement Mode Mosfet - SOT-23-3
得捷:
MOSFET P-CH 60V 900MA SOT23
立创商城:
P沟道 60V 900mA
贸泽:
MOSFET 60V P-Ch Enh Fet 20Vgs 625pD 219pF
艾睿:
Amplify electronic signals and switch between them with the help of Diodes Zetex&s;s ZXMP6A13FQTA power MOSFET. Its maximum power dissipation is 806 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This P channel MOSFET transistor operates in enhancement mode. This MOSFET transistor has a minimum operating temperature of -55 °C and a maximum of 150 °C.
安富利:
Trans MOSFET P-CH 60V 1.1A 3-Pin SOT-23 T/R
Win Source:
MOSFET P-CH 60V 0.9A SOT23-3
针脚数 3
漏源极电阻 0.4 Ω
极性 P-CH
耗散功率 625 mW
漏源极电压Vds 60 V
连续漏极电流Ids 1.1A
上升时间 2.2 ns
输入电容Ciss 219pF @30VVds
额定功率Max 625 mW
下降时间 5.7 ns
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 806 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
封装 SOT-23-3
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
