Littelfuse 473 系列延时Littelfuse 473 系列是时滞类型的熔丝。 适用于需要增强浪涌耐节省空间超微型封装的应用。### 认可UL ### 印刷电路板线端 - 超微型### 印刷电路板线端所有熔丝均为热塑聚酰胺主体
473 系列延时
Littelfuse 473 系列是时滞类型的熔丝。 适用于需要增强浪涌耐节省空间超微型封装的应用。
### 认可
UL
### 印刷电路板线端
所有熔丝均为热塑聚酰胺主体
欧时:
Littelfuse 保险管, 熔断速度 T, 5A, 直径 3.43mm, 3.4 x 7.1mm, 125V ac/dc
立创商城:
5A 125V 延时型
艾睿:
Be protected by adding a subminiature 0473005.MRT1L fuse developed by Littelfuse. This device has a current rating of 5. This fuse has an operating temperature range of -55 °C to 125 °C. It has 2 terminals. The 0473005.MRT1L fuse has an axial termination style. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 7.11 mm long with a diameter of 3.18 mm. Its fuse is made from epoxy coated. The maximum AC voltage rating is 125 VAC and the maximum DC voltage rating is 125 VDC.
Allied Electronics:
Fuse; Submin; Slow Blow; 5A; Supplemental; Dims 0.125x0.28"; Encapsulated; Axial; PCB
Chip1Stop:
Fuse Subminiature Slow Blow Acting 5A 125V Axial 3.175 X 7.11mm Epoxy Coated T/R CSA/UL
TME:
Fuse: fuse; time-lag; axial; 5A; 125V; 3,175x7,11mm; Package: reel
Verical:
Fuse Subminiature Slow Blow Acting 5A 125V Axial 3.43 X 7.11mm Epoxy Coated T/R CSA/UL
Newark:
# LITTELFUSE 0473005.MRT1L Fuse, PCB Leaded, 5 A, 125 VAC, PICO II Series, 125 VDC, Slow Blow, Axial Leaded
额定电压DC 125 V
额定电压AC 125 V
额定电流 5 A
易燃性等级 UL 94 V-0
电阻 0.0133 Ω
电阻DC) 0.0133 Ω
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 125 V
额定电压DC Max 125 V
额定电压AC Max 125 V
安装方式 Through Hole
引脚数 2
封装 Axial
长度 7.11 mm
直径 3.17 mm
封装 Axial
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
0473005.MRT1L Littelfuse 力特 | 当前型号 | 当前型号 |
0473005.MAT1L 力特 | 完全替代 | 0473005.MRT1L和0473005.MAT1L的区别 |
0473005.YRT1L 力特 | 完全替代 | 0473005.MRT1L和0473005.YRT1L的区别 |
0471005.MAT1L 力特 | 完全替代 | 0473005.MRT1L和0471005.MAT1L的区别 |
