0466.250NR

LITTELFUSE  0466.250NR  熔丝, SMD 快速熔断0.25A

额定电流Current Rating| 0.25A \---|--- 额定电压ACVoltage Rating - AC| 125V 额定电压DCVoltage Rating - DC| 125V 分断能力Interrupting Rating| 50A 熔断积分I2T A2secMelting I²t| 0.01126 Description & Applications| •THIN-FILM SURFACE MOUNT •Very Fast-Acting Thin-Film Type 描述与应用| •薄膜表面贴装 •非常快熔型薄膜型

欧时:
### 薄膜表面安装熔丝极小，薄型设计 1206 外壳样式 环氧基片体，铜；镍；锡-铅帽 ### 认可经过 UL 认可和 CSA 认证### 表面安装技术_超微型熔丝架### 表面安装技术表面安装熔丝适用于低电压应用，可大大节省空间（和时间）。 FF 类型最适用于保护高值硅 IC，例如，报警系统、音频/视频设备、计算机板、便携式电话、电源和医疗仪器等等

立创商城:
250mA 125V 快断

贸泽:
表面贴装式保险丝 125V .25A VFA Slimline

e络盟:
表面安装保险丝, 250 mA, 466系列, 125 VAC, 125 VDC, 非常快速反应, 1206

艾睿:
Be protected by adding a chip 0466.250NR fuse developed by Littelfuse. This device has a current rating of 0.25. This fuse has an operating temperature range of -50 °C to 90 °C. It has 2 terminals. The 0466.250NR fuse has a solder pad termination style. Mount your fuse on a printed circuit board using surface mount technology to produce the most effective results. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. The maximum AC voltage rating is 125 VAC and the maximum DC voltage rating is 125 VDC. This product is 3.18 mm long, 0.58 mm tall and 1.52 mm deep.

Allied Electronics:
FUSE BOARD MNT 250MA 125VAC/VDC

Chip1Stop:
Fuse Chip Very Fast Acting 0.25A 125V SMD Solder Pad 1206 T/R

Verical:
Fuse Chip Very Fast Acting 0.25A 125V SMD Solder Pad 1206 T/R CSA

Newark:
# LITTELFUSE  0466.250NR  Fuse, Surface Mount, 466 Series, 250 mA, 125 VAC, 125 VDC, Very Fast Acting, 1206

儒卓力:
**0.25A 125V veryfast 1206 SMDSLI **

Win Source:
FUSE BOARD MNT 250MA 125VAC/VDC
