0441119

PHOENIX CONTACT  0441119  接线端子, DIN导轨安装, 2 路, 24 AWG, 12 AWG, 4 mm²

通用端子

通用端子，采用聚酰胺模制，适合 G 和顶帽导轨。

螺钉导线，使用闭合螺丝刀轴进行保护。 可提供 2.5mm² 到 35mm² 导线尺寸。 该系列由灰色（相位）、蓝色（中性）和黄色/绿色（接地）端子组成。 也可提供 10 路插入（跳接）桥接，与 35mm 导轨端支架一样。

**各个端子和补充附件**

**认证类别：II 2 GD EEx e II 证书 编号 KEMA 98ATEX1651U**

得捷:
CONN TERM BLK GROUND 12-30AWG

欧时:
Phoenix Contact 0441119 绿色/黄色 2 路 接地端子块 DIN 导轨, 螺钉拧紧端接, 24 → 12 AWG线规格

e络盟:
接线端子, DIN导轨安装, 2 路, 24 AWG, 12 AWG, 4 mm²

艾睿:
Phoenix Contact&s;s 0441119 PCB terminal block will ensure strong connections between circuits. This F connector has 2 F contacts. It has a female type gender. It has a straight body orientation. This is a 1-row connector. 0441119 is housed in polyamide. This product is 42.5 mm long, 49.5 mm tall and 5.2 mm deep. It uses the screw termination method. Its wire is 12-24 AWG.

Allied Electronics:
Conn; Term Blk; DIN Rail; Grd; Screw; .2-4 sq.mm; 24-12AWG; 5.2mm W; Green-YL

Chip1Stop:
Conn Ground Modular Terminal Block F 2 POS Screw ST G DIN Rail/T DIN Rail

Verical:
Conn Ground Modular Terminal Block F 2 POS Screw ST G DIN Rail/T DIN Rail

Newark:
# PHOENIX CONTACT  0441119  DIN Rail Mount Terminal Block, 2 Positions, 24 AWG, 12 AWG, 4 mm², Screw

MASTER:
Ground modular terminal block - connection method: Screw connection - number of connections: 2 - number of positions: 1 - cross section: 0.2 mm² - 4 mm² - AWG: 24 - 12 - width: 5.2 mm - color: green-yellow - mounting type: NS 35/7,5 - NS 35/15 - NS 32

Online Components:
Conn Ground Modular Terminal Block F 2 POS Screw ST G DIN Rail/T DIN Rail

Electro Sonic:
Ground modular terminal block - connection method: Screw connection - number of connections: 2 - number of positions: 1 - ...
