0235001.HXP

235 系列 快熔型 250 V 1 A 5 x 20 mm 玻璃管 保险丝

235 Series fast-acting glass fuses are designed to UL/CSA/ANCE 248 Standard.

.

*Agency Approvals:** UL listed, CSA Certified, Approved by METI from 1-5 amps. **Blow Time:** 110%, 4 hour minimum; 135%, 1 hour maximum; 200%, 5 seconds maximum.

欧时:
Fuse Fast Acting 1A 5x20mm Glass

立创商城:
1A 250V 快断

贸泽:
保险丝管 250V 1A Fast Acting

艾睿:
Be protected by adding a miniature 0235001.HXP fuse developed by Littelfuse. This device has a current rating of 1. This fuse has an operating temperature range of -55 °C to 125 °C. It has 2 terminals. The 0235001.HXP fuse has a cartridge termination style. This product comes packaged in bulk, so the parts will be stored loosely. This product is 20 mm long with a diameter of 5.2 mm. Its fuse is made from glass. The maximum AC voltage rating is 250 VAC.

Allied Electronics:
Fuse; Cylinder; Fast Acting; 1A; Dims 5x20mm; Glass; Cartridge; 250VAC; 0.153Ohms; Clip

Chip1Stop:
Fuse Miniature Fast Acting 1A 250V Holder Cartridge 5 X 20mm Glass Bulk CE/CSA/PSE/UL

Verical:
Fuse Miniature Fast Acting 1A 250V Holder Cartridge 5 X 20mm Glass Bulk CE/CSA/PSE/UL

Newark:
# LITTELFUSE  0235001.HXP  Fuse, Cartridge, 235 Series, 1 A, 250 V, 5mm x 20mm, 0.2" x 0.79", 100 A

儒卓力:
**1A 250V fast 5x20 glass UL **
