2.54毫米（ .100 ）间距KK®线对板头，单列，立式， 9电路，PA聚酰胺尼龙，锡（Sn ）镀层 2.54mm .100 Pitch KK® Wire-to-Board Header, Single Row, Vertical, 9 Circuits, PA Polyamide Nylon, Tin Sn Plating
Connector Header Through Hole 9 position 0.100" 2.54mm
得捷:
CONN HEADER VERT 9POS 2.54MM
贸泽:
Headers & Wire Housings KK .100" HDR 09P VT SN
艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded 0022032091 header connector from Molex. This HDR connector&s;s 9 contacts that are made out of brass and plated with tin over copper. Its pitch is 2.54 mm. This is a 1-row connector. It has a maximum voltage rating of 250 V. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 4 A/contact. It uses the solder termination method. 0022032091 is housed in white nylon. This connector has an operating temperature of -40 to 80 °C. This product is 22.61 mm long, 10.79 mm tall and 2.34 mm deep.
安富利:
Conn Unshrouded Header HDR 9 POS 2.54mm Solder ST Thru-Hole Bulk
