LITTELFUSE 0251010.MAT1L 保险丝, 快熔型, 10A
The is a 10A/125V very fast acting Quick Blow Fuse with encapsulated/epoxy-coated ceramic body, pure tin coated copper wire leads and axial leaded case. This halogen-free fuse features low temperature rerating. Designed to meet an extensive array of performance characteristics in a space-saving subminiature.
- .
- Small size
- .
- 0.00705R Nominal cold resistance
- .
- -55 to 125°C Operating temperature range
- .
- UL94V-0 Flammability rating
额定电压DC 125 V
额定电压AC 125 V
额定电流 10 A
易燃性等级 UL 94 V-0
电阻 0.00705 Ω
工作温度Max 125 ℃
工作温度Min -55 ℃
安装方式 Through Hole
引脚数 2
封装 轴向引线
长度 7.11 mm
直径 2.41 mm
封装 轴向引线
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape, Ammo Pack
制造应用 Safety, 安全
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
0251010.MAT1L Littelfuse 力特 | 当前型号 | 当前型号 |
0251010.MRT1L 力特 | 完全替代 | 0251010.MAT1L和0251010.MRT1L的区别 |
0251010.HAT1L 力特 | 完全替代 | 0251010.MAT1L和0251010.HAT1L的区别 |
0251010.NRT1L 力特 | 完全替代 | 0251010.MAT1L和0251010.NRT1L的区别 |
