01763.35.04

01763.35.04图片1
01763.35.04图片2
01763.35.04图片3
01763.35.04图片4
01763.35.04图片5
01763.35.04概述

Industrial-Grade Welding Cable, 2/0 Cls m Weld Cbl-Org-250 Rl

Welding cable available in sizes 6 through 4/0 AWG is constructed with fully annealed stranded bare copper per ATTM B172 Class M. Fine strand construction makes this cable very flexible and assures a longer service life. Orange Super Vu-Tron jacket is abrasion resistant with a temperature range of –50 degrees to 90 degrees Centigrade.


Allied Electronics:
HOOK-UP STRND 2/0 AWG ORG 250"


01763.35.04中文资料参数规格
技术参数

额定电流 300 A

芯数 1

额定电压 600 VAC

外形尺寸

长度 76.2 m

物理参数

工作温度 -50℃ ~ 90℃

其他

产品生命周期 Active

包装方式 Coil

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买01763.35.04
型号: 01763.35.04
制造商: General Cable
描述:Industrial-Grade Welding Cable, 2/0 Cls m Weld Cbl-Org-250 Rl
