0387600108图片1
0387600108图片2
0387600108图片3
0387600108图片4
0387600108概述

Conn Barrier Strip 16POS 9.53mm Screw ST Panel Mount

8 电路 0.375"(9.53mm) 隔板接线座 螺钉


得捷:
CONN BARRIER STRIP 8CIRC 0.375"


艾睿:
Know that you will have strong connections between circuits when you use Molex&s;s barrier strip 0387600108 PCB terminal block. Its pitch is 9.53 mm. It has a straight body orientation. This is a 2-row connector. 0387600108 is housed in thermoplastic. It uses the screw termination method. This product is 92.8 mm long, 22.4 mm tall and 16 mm deep.


安富利:
Conn Barrier Strip 16 POS 9.53mm Screw ST Panel Mount


Verical:
Conn Barrier Strip 16 POS 9.53mm Panel Mount 15A


0387600108中文资料参数规格
技术参数

触点数 16

线规 14AWG ~ 22AWG

排数 2

电路数 8

额定电流Max 15 A

额定电压Max 300 V

额定电压 300 V

工作电压Max 300 V

封装参数

安装方式 Panel, Screw

外形尺寸

高度 22.4 mm

物理参数

外壳颜色 Black

颜色 Black

触点材质 Brass, Steel

其他

产品生命周期 Unknown

包装方式 Tray

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买0387600108
型号: 0387600108
制造商: Molex 莫仕
描述:Conn Barrier Strip 16POS 9.53mm Screw ST Panel Mount
