保险丝, 自复式 PTC, 6VDC, 2A, SMD
Resuming operation after a fuse burns out has never been more convenient with this PTC resettable fuse from Bel Fuse! This device has a maximum current rating of 100. This resettable fuse has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has 2 terminals. Mount your resettable fuse on a printed circuit board using surface mount technology to produce the most effective results. This product is 3.5Max mm long, 1.6Max mm tall and 1.8Max mm deep.
跳闸时间 1.5 s
耗散功率 0.8 W
电阻 0.08 Ω
保持电流 2 A
跳闸电流 3.5 A
额定电流Max 100 A
保持电流Max 2 A
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压Max 6 VDC
额定电压 6 VDC
工作电压Max 6 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 1.6 mm
封装公制 3216
封装 1206
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
