0603 2.2 pF 200 V U2J +-0.1 容差 SMD 陶瓷电容
±0.1pF 200V 陶瓷器 C0G,NP0 0603(1608 公制)
得捷:
CAP CER 2.2PF 200V NP0 0603
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 200V 2.2pF C0G 0603 .1pF Tol
艾睿:
This 06032U2R2BAT2A multilayer ceramic capacitor from AVX has so many uses that it even has a standard classification system for all its uses! It can withstand a voltage of 200 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its capacitance value is 2.2pF. This product is 1.52 mm long, 0.91Max mm tall and 0.76 mm deep.
安富利:
C0G NP0 chip capacitors specially designed for “Ultra” low ESR for applications in the communications market. Max ESR and effective capacitance are met on each value producing lot to lot uniformity. Sizes available are EIA chip sizes 0402, 0603, 0805, and 1210.
额定电压DC 200 V
电容 2.2 pF
容差 ±0.1 pF
工作温度Max 125 ℃
工作温度Min 55 ℃
额定电压 200 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.81 mm
高度 0.91 mm
封装公制 1608
封装 0603
材质 NP0/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 RF,微波,高频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
06032U2R2BAT2A AVX 艾维克斯 | 当前型号 | 当前型号 |
06032U2R2CAT2A 艾维克斯 | 类似代替 | 06032U2R2BAT2A和06032U2R2CAT2A的区别 |
C0603C229C2GACTU 基美 | 功能相似 | 06032U2R2BAT2A和C0603C229C2GACTU的区别 |
