0225007.HXUP

225分之224系列无铅2AG ，快熔型 224/225 Series Lead-Free 2AG, Fast-Acting

The 2AG fuse provides the same performance characteristics as the universal standard 3AG design in less than one-third the space. These subminiature fuses offer top quality, reliability and space-saving protection for your new designs. Available with pigtail leads for direct soldering or for use with #111501 mating PCB fuse clips. The 2AG Series is UL and CSA Approved.

贸泽:
保险丝管 125V 7A

艾睿:
A great alternative to a circuit breaker, this a subminiature 0225007.HXUP fuse from Littelfuse will protect your electronics. This device has a current rating of 7. This fuse has a minimum operating temperature of -55 °C and a maximum of 125 °C. It has 2 terminals. The 0225007.HXUP fuse has a cartridge termination style. This product comes packaged in bulk, so the parts will be stored loosely. This product is 14.48 mm long with a diameter of 4.5 mm. The maximum AC voltage rating is 125 VAC. Its fuse is made from glass.

Allied Electronics:
Fuse; Cylinder; Fast Acting; 7A; Sz 2AG; Supplemental; Dims 0.177x0.57"; Glass; 125VAC

Chip1Stop:
Fuse Subminiature Fast Acting 7A 125V Holder Cartridge 5 X 15mm Glass Bulk

Verical:
Fuse Subminiature Fast Acting 7A 125V Holder Cartridge 5 X 15mm Glass Bulk CE/CSA/PSE/UL

Newark:
# LITTELFUSE  0225007.HXUP  Fuse, Cartridge, 225 Series, 7 A, 125 V, 5mm x 15mm, 500 A
