PTC Resettable Fuse 0.65Ahold 1.3Atrip 120VDC/120VAC 5A 1.68W 5.7s 0.31Ω Radial 9.7 X 3.8mm Bulk
This PTC resettable fuse from Bel Fuse is ideal for low current and low voltage ratings. This part has a lead diameter of 0.65 mm. This device has a maximum current rating of 5. This resettable fuse has an operating temperature range of -40 °C to 85 °C. It has 2 terminals. This product is 3.8Max mm deep. This product"s terminal pitch is 5.1typ mm.
得捷:
PTC RESET FUSE 120V 650MA RADIAL
立创商城:
0ZRM0065FF1E
艾睿:
PTC Resettable Fuse 0.65Ahold 1.3Atrip 120VDC/120VAC 5A 1.68W 5.7s 0.31Ohm Radial 9.7 X 3.8mm Bulk Automotive
安富利:
PTC Resettable Fuse 5A 120VDC/120VAC Bulk
Chip1Stop:
PTC Resettable Fuse 0.65Ahold 1.3Atrip 120VDC/120VAC 5A 1.68W 5.7s 0.31Ohm Radial 9.7 X 3.8mm Bulk
跳闸时间 5.7 s
耗散功率 1.68 W
电阻 0.72 Ω
保持电流 0.65 A
跳闸电流 1.3 A
额定电流Max 5 A
保持电流Max 650 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Through Hole
引脚数 2
封装 Radial, Disc
长度 9.7 mm
宽度 3.8 mm
高度 9.7 mm
封装 Radial, Disc
厚度 3.8 mm
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
