0719207概述

Conn Feed-Through Modular Terminal Blocks 1POS Screw Cable Mount 41A

Conn Feed-Through Modular Terminal Blocks 1 POS Screw Cable Mount 41A


得捷:
CONN TERM BLK FEED THRU 10-30AWG


艾睿:
Conn Feed-Through Modular Terminal Block 1 POS Screw Cable Mount 41A


Verical:
Conn Feed-Through Modular Terminal Block 1 POS Screw Cable Mount 32A


MASTER:
Feed-through terminal block - nom. voltage: 800 V - nominal current: 32 A - connection method: Screw connection - number of connections: 2 - number of positions: 1 - cross section: 0.2 mm² - 6 mm² - AWG: 24 - 10 - width: 6.2 mm - color: beige - mounting


Online Components:
Conn Feed-Through Modular Terminal Blocks 1 POS Screw Cable Mount 41A


Electro Sonic:
Feed-through terminal block - nom. voltage: 800 V - nominal current: 32 A - connection method: Screw connection - number ...


0719207中文资料参数规格
技术参数

触点数 1

线规 10AWG ~ 30AWG

排数 1

电路数 1

易燃性等级 UL 94 V-0

针脚数 2

额定电流Max 41 A

额定电压Max 800 V

工作电压Max 800 V

封装参数

安装方式 DIN Rail

外形尺寸

宽度 6.2 mm

物理参数

外壳颜色 Beige

颜色 Beige

其他

产品生命周期 Active

包装方式 Bulk

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

海关信息

ECCN代码 EAR99

HTS代码 8536904000

数据手册

在线购买0719207
型号: 0719207
描述:Conn Feed-Through Modular Terminal Blocks 1POS Screw Cable Mount 41A
